Description
This 2×8 Character LCD display has a Black on Grey appearance, and its construction is Chip-on-board. The interface is Parallel and it has Eng / Jap font sets.
Image shown is a representation only. Exact specifications should be obtained from the product specification document
This 2×8 Character LCD display has a Black on Grey appearance, and its construction is Chip-on-board. The interface is Parallel and it has Eng / Jap font sets.
This 2×8 Character LCD display has a Black on Grey appearance, and its construction is Chip-on-board. The interface is Parallel and it has Eng / Jap font sets.
Demo code and more useful information is available on the support and download centre.
| Product Type | Character |
| Format | 2x8 |
| Character Height (mm) | 3 |
| Module Dimensions (mm) | 25.0 x 17.5 |
| Viewing Area (mm) | 21.0 x 9.0 |
| Mode | Positive Reflective |
| Backlight | Reflective |
| Appearance | Black on Grey |
| Interface | Parallel |
| Voltage | 5V |
| Font Sets | Eng / Jap |
| Operating Temperature (°C) | -20 to +70 |
| Construction | Chip-on-board |
| Controller | ST7066 |
| Connection Number | 16 |
| Connection Pitch (mm) | 1.27 |
